--- title: Dual in-line Leadframes, Dual in-line Pin, Edge clip connectors description: Dual In-Line Leadframes for resistor networks, hybrid circuits, and PCB terminations. Streamline your process and maximize system stability --- # Dual In-Line Leadframes Dual in-line configuration allows for a streamlined assembly process, operational efficiency and overall system stability. Also known as Dual In Line Pin as well as edge clip connectors. Typical applications include resistor networks, hybrid circuits and PCB terminations. DIL leadframes are available with pitches of 1.27mm to 2.54mm, and “F” and “G” outlines as detailed in the catalogue. Customised versions and special designs are also possible. ## Dual In-Line Pins A crucial component for ensuring secure and reliable connections within electronic circuits, catering to a wide range of applications. ### Features - Through hole mount - Standard Pitch Sizes - Edge or central mounting - Break-off tie bars top & bottom - Multiple orientation options available - Multiple plating options - Multiple material options ### Benefits - Low cost effective solution for through hole board to board interconnect - High reliability - Provides framework for board stacks - Maximises available board space - Easy rework capability - Low set-up costs --- ### F Type ![DIL-F-Type](https://www.batten-allen.com/hs-fs/hubfs/Images/DIL-F-Type.png?width=300&height=117&name=DIL-F-Type.png)   [ Download Spec & Parts List ](https://www.batten-allen.com/hubfs/Downloads/DIL-F-Type-2021.pdf) ### G Type ![DIL-G-Type](https://www.batten-allen.com/hs-fs/hubfs/Images/DIL-G-Type.png?width=282&height=139&name=DIL-G-Type.png)   [ Download Component key ](https://www.batten-allen.com/hubfs/Downloads/DIL-G-Type-2021.pdf) ### Component Ordering Key [ Download Component key ](https://www.batten-allen.com/hubfs/Downloads/Component-Specifications.pdf)   ## News and insights Everything about the market, Batten & Allen and the services we offer to give you the competitive edge. ###### 2 min read #### [New Partnership to Meet Growing Demand for Lead Frames in North America](https://www.batten-allen.com/news/new-partnership-lead-frames-north-america) Batten & Allen: Feb 19, 2026 UK’s Batten & Allen forges new alliance with USA’s Neu Dynamics – see them at APEC, March 22-26, 2026 at the Henry B.... ###### 2 min read #### [New ‘Tube Map’ Online Resource For Stamped/Plated Components](https://www.batten-allen.com/news/new-online-resource-for-stamping-plating) Batten & Allen: Aug 29, 2025 Batten & Allen makes parts specification quicker and easier World-class stamping and plating specialist Batten & Allen... #### [Infographic: Batten & Allen's Turnkey Process From Concept to Delivery](https://www.batten-allen.com/news/infographic-batten-allens-turnkey-process-from-concept-to-delivery) Batten & Allen: Jan 13, 2025 To discuss your turnkey solutions with our expert team please get in touch. ### Explore Our Dual In-Line Leadframes! Discover the versatility of our Dual In-Line Leadframes, perfect for resistor networks, hybrid circuits, and PCB terminations. Available in various pitches and customized designs to suit your needs. [Contact Us](https://www.batten-allen.com/product-enquiry) ![bsilogos](https://www.batten-allen.com/hs-fs/hubfs/bsilogos.png?width=759&height=253&name=bsilogos.png) ![logo4-e1574677024879](https://www.batten-allen.com/hs-fs/hubfs/logo4-e1574677024879.png?width=100&height=83&name=logo4-e1574677024879.png) ![logo5-e1574677048431](https://www.batten-allen.com/hs-fs/hubfs/logo5-e1574677048431.png?width=100&height=83&name=logo5-e1574677048431.png) ![logo3-e1574677018761](https://www.batten-allen.com/hs-fs/hubfs/logo3-e1574677018761.png?width=100&height=83&name=logo3-e1574677018761.png) ![logo2-e1574677012745](https://www.batten-allen.com/hs-fs/hubfs/logo2-e1574677012745.png?width=100&height=83&name=logo2-e1574677012745.png) ![ITSA](https://www.batten-allen.com/hs-fs/hubfs/ITSA.png?width=300&height=127&name=ITSA.png) ![logo-temp](https://dl.dropboxusercontent.com/s/gxscpz603y2nfcs/logo-temp.png)
